Katacoda在线课：Networking Introduction
本系列教程希望能通过交互式学习网站与传统方式结合，更高效、容易的学习知识。 本系列教程将使用 Katacoda在线学习平台 完成学习。
Kubernetes 具有先进的网络功能，允许 Pod 和 Service 在集群网络内部和外部进行通信。
在此场景中，您将学习以下类型的 Kubernetes Service。
- Cluster IP
- Target Ports
- NodePort
- External IPs
- Load Balancer
Kubernetes 服务是一个抽象，它定义了如何访问一组 Pod 的策略和方法。可以通过 Service 访问基于标签选择器的 Pod 集合。
Cluster IP
Cluster IP 是创建 Kubernetes 服务时的默认方法。该服务被分配了一个内部 IP，其他组件可以使用它来访问 Pod。
Service 能够通过单个 IP 地址在多个 Pod 之间进行负载平衡。
通过 kubectl apply -f clusterip.yaml 命令部署服务。
在 cat clusterip.yaml 可以查看相关定义。
clusterip.yaml
apiVersion: v1
kind: Service
metadata:
name: webapp1-clusterip-svc
labels:
app: webapp1-clusterip
spec:
ports:
- port: 80
selector:
app: webapp1-clusterip
---
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: webapp1-clusterip-deployment
spec:
replicas: 2
template:
metadata:
labels:
app: webapp1-clusterip
spec:
containers:
- name: webapp1-clusterip-pod
image: katacoda/docker-http-server:latest
ports:
- containerPort: 80
---
controlplane $ kubectl apply -f clusterip.yaml
service/webapp1-clusterip-svc created
deployment.extensions/webapp1-clusterip-deployment created
该文件定义了部署具有两个副本的 Web 应用程序，用来展示负载平衡和服务。
可以通过 kubectl get pods 命令查看 Pod 状态。
controlplane $ kubectl get pods
NAME READY STATUS RESTARTS AGE
webapp1-clusterip-deployment-669c7c65c4-r6k2l 1/1 Running 0 15s
webapp1-clusterip-deployment-669c7c65c4-xdsd4 1/1 Running 0 15s
同时也部署了一个 Service，可以通过 kubectl get svc 命令查看。
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 8m12s
webapp1-clusterip-svc ClusterIP 10.108.32.169 <none> 80/TCP 39s
可以通过 kubectl describe svc/webapp1-clusterip-svc 命令查看有关服务配置和活动端点 (Pod) 的更多详细信息
controlplane $ kubectl describe svc/webapp1-clusterip-svc
Name: webapp1-clusterip-svc
Namespace: default
Labels: app=webapp1-clusterip
Annotations: kubectl.kubernetes.io/last-applied-configuration:
{"apiVersion":"v1","kind":"Service","metadata":{"annotations":{},"labels":{"app":"webapp1-clusterip"},"name":"webapp1-clusterip-svc","name...
Selector: app=webapp1-clusterip
Type: ClusterIP
IP: 10.108.32.169
Port: <unset> 80/TCP
TargetPort: 80/TCP
Endpoints: 10.32.0.5:80,10.32.0.6:80
Session Affinity: None
Events: <none>
部署完成后，可以通过分配的 Cluster IP 访问该服务。
controlplane $ export CLUSTER_IP=$(kubectl get services/webapp1-clusterip-svc -o go-template='{{(index .spec.clusterIP)}}')
controlplane $ echo CLUSTER_IP=$CLUSTER_IP
CLUSTER_IP=10.108.32.169
controlplane $ curl $CLUSTER_IP:80
<h1>This request was processed by host: webapp1-clusterip-deployment-669c7c65c4-r6k2l</h1>
将通过多个请求来展示基于公共标签选择器的跨多个* Pod* 的负载均衡器。
controlplane $ curl $CLUSTER_IP:80
<h1>This request was processed by host: webapp1-clusterip-deployment-669c7c65c4-xdsd4</h1>
controlplane $ curl $CLUSTER_IP:80
<h1>This request was processed by host: webapp1-clusterip-deployment-669c7c65c4-r6k2l</h1>
Target Port
TargetPort 允许我们将服务可用的端口与应用程序正在侦听的端口分开。 TargetPort 是应用配置为侦听的端口。端口是从外部访问应用的方式。
与之前类似，Service 和额外的 Pod 是通过 kubectl apply -f clusterip-target.yaml 命令来部署的。
**clusterip-target.yaml **
apiVersion: v1
kind: Service
metadata:
name: webapp1-clusterip-targetport-svc
labels:
app: webapp1-clusterip-targetport
spec:
ports:
- port: 8080
targetPort: 80
selector:
app: webapp1-clusterip-targetport
---
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: webapp1-clusterip-targetport-deployment
spec:
replicas: 2
template:
metadata:
labels:
app: webapp1-clusterip-targetport
spec:
containers:
- name: webapp1-clusterip-targetport-pod
image: katacoda/docker-http-server:latest
ports:
- containerPort: 80
---
以下命令将创建服务。
controlplane $ kubectl apply -f clusterip-target.yaml
service/webapp1-clusterip-targetport-svc created
deployment.extensions/webapp1-clusterip-targetport-deployment created
controlplane $ kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 13m
webapp1-clusterip-svc ClusterIP 10.108.32.169 <none> 80/TCP 5m29s
webapp1-clusterip-targetport-svc ClusterIP 10.102.59.206 <none> 8080/TCP 40s
controlplane $ kubectl describe svc/webapp1-clusterip-targetport-svc
Name: webapp1-clusterip-targetport-svc
Namespace: default
Labels: app=webapp1-clusterip-targetport
Annotations: kubectl.kubernetes.io/last-applied-configuration:
{"apiVersion":"v1","kind":"Service","metadata":{"annotations":{},"labels":{"app":"webapp1-clusterip-targetport"},"name":"webapp1-clusterip...
Selector: app=webapp1-clusterip-targetport
Type: ClusterIP
IP: 10.102.59.206
Port: <unset> 8080/TCP
TargetPort: 80/TCP
Endpoints: 10.32.0.7:80,10.32.0.8:80
Session Affinity: None
Events: <none>
Service 和 Pod 部署完成后，可以像以前一样通过 Cluster IP 访问，但这次是在定义的端口 8080 上。
controlplane $ export CLUSTER_IP=$(kubectl get services/webapp1-clusterip-targetport-svc -o go-template='{{(index .spec.clusterIP)}}')
controlplane $ echo CLUSTER_IP=$CLUSTER_IP
CLUSTER_IP=10.102.59.206
controlplane $ curl $CLUSTER_IP:8080
<h1>This request was processed by host: webapp1-clusterip-targetport-deployment-5599945ff4-96fqh</h1>
controlplane $ curl $CLUSTER_IP:8080
<h1>This request was processed by host: webapp1-clusterip-targetport-deployment-5599945ff4-zwr8f</h1>
应用程序本身仍然配置为侦听 80 端口。Kubernetes 服务管理着两者之间的转换。
NodePort
虽然 TargetPort 和 ClusterIP 使其可用于集群内部，但 NodePort 通过定义的静态端口在每个节点的 IP 上公开服务。无论访问集群内的哪个节点，都可以通过定义的端口号直接访问该服务。
controlplane $ kubectl apply -f nodeport.yaml
service/webapp1-nodeport-svc created
deployment.extensions/webapp1-nodeport-deployment created
查看服务定义时，注意定义的附加类型和 NodePort 属性。
nodeport.yaml
apiVersion: v1
kind: Service
metadata:
name: webapp1-nodeport-svc
labels:
app: webapp1-nodeport
spec:
type: NodePort
ports:
- port: 80
nodePort: 30080
selector:
app: webapp1-nodeport
---
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: webapp1-nodeport-deployment
spec:
replicas: 2
template:
metadata:
labels:
app: webapp1-nodeport
spec:
containers:
- name: webapp1-nodeport-pod
image: katacoda/docker-http-server:latest
ports:
- containerPort: 80
---
controlplane $ kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 22m
webapp1-clusterip-svc ClusterIP 10.108.32.169 <none> 80/TCP 14m
webapp1-clusterip-targetport-svc ClusterIP 10.102.59.206 <none> 8080/TCP 9m44s
webapp1-nodeport-svc NodePort 10.102.135.99 <none> 80:30080/TCP 5m52s
controlplane $ kubectl describe svc/webapp1-nodeport-svc
Name: webapp1-nodeport-svc
Namespace: default
Labels: app=webapp1-nodeport
Annotations: kubectl.kubernetes.io/last-applied-configuration:
{"apiVersion":"v1","kind":"Service","metadata":{"annotations":{},"labels":{"app":"webapp1-nodeport"},"name":"webapp1-nodeport-svc","namesp...
Selector: app=webapp1-nodeport
Type: NodePort
IP: 10.102.135.99
Port: <unset> 80/TCP
TargetPort: 80/TCP
NodePort: <unset> 30080/TCP
Endpoints: 10.32.0.10:80,10.32.0.9:80
Session Affinity: None
External Traffic Policy: Cluster
Events: <none>
可以通过 NodePort 定义的 Node 的 IP 地址访问到服务。
controlplane $ curl 172.17.0.31:30080
<h1>This request was processed by host: webapp1-nodeport-deployment-677bd89b96-j256b</h1>
controlplane $ curl 172.17.0.31:30080
<h1>This request was processed by host: webapp1-nodeport-deployment-677bd89b96-88qj5</h1>
External IP
另一种方法是通过外部 IP 地址让服务在集群外可用。
将定义中的 externalIPs 更新为当前集群的 IP 地址
controlplane $ sed -i 's/HOSTIP/172.17.0.31/g' externalip.yaml
externalip.yaml
apiVersion: v1
kind: Service
metadata:
name: webapp1-externalip-svc
labels:
app: webapp1-externalip
spec:
ports:
- port: 80
externalIPs:
- 172.17.0.30
selector:
app: webapp1-externalip
---
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: webapp1-externalip-deployment
spec:
replicas: 2
template:
metadata:
labels:
app: webapp1-externalip
spec:
containers:
- name: webapp1-externalip-pod
image: katacoda/docker-http-server:latest
ports:
- containerPort: 80
---
controlplane $ cat externalip.yaml
apiVersion: v1
kind: Service
metadata:
name: webapp1-externalip-svc
labels:
app: webapp1-externalip
spec:
ports:
- port: 80
externalIPs:
- 172.17.0.30
selector:
app: webapp1-externalip
---
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: webapp1-externalip-deployment
spec:
replicas: 2
template:
metadata:
labels:
app: webapp1-externalip
spec:
containers:
- name: webapp1-externalip-pod
image: katacoda/docker-http-server:latest
ports:
- containerPort: 80
---
controlplane $ kubectl apply -f externalip.yaml
service/webapp1-externalip-svc created
deployment.extensions/webapp1-externalip-deployment created
controlplane $ kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 28m
webapp1-clusterip-svc ClusterIP 10.108.32.169 <none> 80/TCP 20m
webapp1-clusterip-targetport-svc ClusterIP 10.102.59.206 <none> 8080/TCP 15m
webapp1-externalip-svc ClusterIP 10.109.28.108 172.17.0.31 80/TCP 8s
webapp1-nodeport-svc NodePort 10.102.135.99 <none> 80:30080/TCP 12m
controlplane $ kubectl describe svc/webapp1-externalip-svc
Name: webapp1-externalip-svc
Namespace: default
Labels: app=webapp1-externalip
Annotations: kubectl.kubernetes.io/last-applied-configuration:
{"apiVersion":"v1","kind":"Service","metadata":{"annotations":{},"labels":{"app":"webapp1-externalip"},"name":"webapp1-externalip-svc","na...
Selector: app=webapp1-externalip
Type: ClusterIP
IP: 10.109.28.108
External IPs: 172.17.0.31
Port: <unset> 80/TCP
TargetPort: 80/TCP
Endpoints: 10.32.0.11:80,10.32.0.12:80
Session Affinity: None
Events: <none>
该服务现在绑定到主节点的 IP 地址和 80端口 。
controlplane $ curl 172.17.0.31
<h1>This request was processed by host: webapp1-externalip-deployment-6446b488f8-dxdb5</h1>
controlplane $ curl 172.17.0.31
<h1>This request was processed by host: webapp1-externalip-deployment-6446b488f8-2zw2p</h1>
Load Balancer
在例如 EC2 或 Azure 的云服务中运行时，可以通过云服务商配置和分配发布的公网 IP 地址。这将通过负载均衡器（例如 ELB）发出，允许将额外的公网 IP 地址分配给 Kubernetes 集群，而无需直接与云提供商交互。
由于 Katacoda 不是云服务商，因此仍然可以为 LoadBalancer 类型的服务动态分配 IP 地址。这是通过使用 kubectl apply -f cloudprovider.yaml 部署 Cloud Provider 来完成的。并不是必需在云服务商提供的服务中运行的。
cloudprovider.yaml
apiVersion: extensions/v1beta1
kind: DaemonSet
metadata:
name: kube-keepalived-vip
namespace: kube-system
spec:
template:
metadata:
labels:
name: kube-keepalived-vip
spec:
hostNetwork: true
containers:
- image: gcr.io/google_containers/kube-keepalived-vip:0.9
name: kube-keepalived-vip
imagePullPolicy: Always
securityContext:
privileged: true
volumeMounts:
- mountPath: /lib/modules
name: modules
readOnly: true
- mountPath: /dev
name: dev
# use downward API
env:
- name: POD_NAME
valueFrom:
fieldRef:
fieldPath: metadata.name
- name: POD_NAMESPACE
valueFrom:
fieldRef:
fieldPath: metadata.namespace
# to use unicast
args:
- --services-configmap=kube-system/vip-configmap
# unicast uses the ip of the nodes instead of multicast
# this is useful if running in cloud providers (like AWS)
#- --use-unicast=true
volumes:
- name: modules
hostPath:
path: /lib/modules
- name: dev
hostPath:
path: /dev
nodeSelector:
# type: worker # adjust this to match your worker nodes
---
## We also create an empty ConfigMap to hold our config
apiVersion: v1
kind: ConfigMap
metadata:
name: vip-configmap
namespace: kube-system
data:
---
apiVersion: apps/v1beta1
kind: Deployment
metadata:
labels:
app: keepalived-cloud-provider
name: keepalived-cloud-provider
namespace: kube-system
spec:
replicas: 1
revisionHistoryLimit: 2
selector:
matchLabels:
app: keepalived-cloud-provider
strategy:
type: RollingUpdate
template:
metadata:
annotations:
scheduler.alpha.kubernetes.io/critical-pod: ""
scheduler.alpha.kubernetes.io/tolerations: '[{"key":"CriticalAddonsOnly", "operator":"Exists"}]'
labels:
app: keepalived-cloud-provider
spec:
containers:
- name: keepalived-cloud-provider
image: quay.io/munnerz/keepalived-cloud-provider:0.0.1
imagePullPolicy: IfNotPresent
env:
- name: KEEPALIVED_NAMESPACE
value: kube-system
- name: KEEPALIVED_CONFIG_MAP
value: vip-configmap
- name: KEEPALIVED_SERVICE_CIDR
value: 10.10.0.0/26 # pick a CIDR that is explicitly reserved for keepalived
volumeMounts:
- name: certs
mountPath: /etc/ssl/certs
resources:
requests:
cpu: 200m
livenessProbe:
httpGet:
path: /healthz
port: 10252
host: 127.0.0.1
initialDelaySeconds: 15
timeoutSeconds: 15
failureThreshold: 8
volumes:
- name: certs
hostPath:
path: /etc/ssl/certs
---
controlplane $ kubectl apply -f cloudprovider.yaml
daemonset.extensions/kube-keepalived-vip configured
configmap/vip-configmap configured
deployment.apps/keepalived-cloud-provider created
当服务请求负载均衡时，负载均衡的提供商将从配置中定义的 10.10.0.0/26 范围中分配一个 IP。
controlplane $ kubectl get pods -n kube-system
NAME READY STATUS RESTARTS AGE
coredns-fb8b8dccf-6rvjq 1/1 Running 0 39m
coredns-fb8b8dccf-p5lxm 1/1 Running 0 39m
etcd-controlplane 1/1 Running 0 38m
katacoda-cloud-provider-66d7758d5d-bn748 1/1 Running 0 39m
keepalived-cloud-provider-78fc4468b-bk8wn 1/1 Running 0 6m16s
kube-apiserver-controlplane 1/1 Running 0 39m
kube-controller-manager-controlplane 1/1 Running 2 39m
kube-keepalived-vip-42ql5 1/1 Running 0 38m
kube-proxy-d5q4m 1/1 Running 0 39m
kube-scheduler-controlplane 1/1 Running 3 39m
weave-net-9rc2g 2/2 Running 1 39m
该服务是通过负载均衡配置的，如 cat loadbalancer.yaml 中所定义所示。
loadbalancer.yaml
apiVersion: v1
kind: Service
metadata:
name: webapp1-loadbalancer-svc
labels:
app: webapp1-loadbalancer
spec:
type: LoadBalancer
ports:
- port: 80
selector:
app: webapp1-loadbalancer
---
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
name: webapp1-loadbalancer-deployment
spec:
replicas: 2
template:
metadata:
labels:
app: webapp1-loadbalancer
spec:
containers:
- name: webapp1-loadbalancer-pod
image: katacoda/docker-http-server:latest
ports:
- containerPort: 80
controlplane $ kubectl apply -f loadbalancer.yaml
service/webapp1-loadbalancer-svc created
deployment.extensions/webapp1-loadbalancer-deployment created
在定义 IP 地址时，服务将显示 Pending。分配后，它将出现在服务列表中。
controlplane $ kubectl get svc
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 38m
webapp1-clusterip-svc ClusterIP 10.108.32.169 <none> 80/TCP 31m
webapp1-clusterip-targetport-svc ClusterIP 10.102.59.206 <none> 8080/TCP 26m
webapp1-externalip-svc ClusterIP 10.109.28.108 172.17.0.31 80/TCP 10m
webapp1-loadbalancer-svc LoadBalancer 10.105.60.108 172.17.0.31 80:30626/TCP 7s
webapp1-nodeport-svc NodePort 10.102.135.99 <none> 80:30080/TCP 22m
controlplane $ kubectl describe svc/webapp1-loadbalancer-svc
Name: webapp1-loadbalancer-svc
Namespace: default
Labels: app=webapp1-loadbalancer
Annotations: kubectl.kubernetes.io/last-applied-configuration:
{"apiVersion":"v1","kind":"Service","metadata":{"annotations":{},"labels":{"app":"webapp1-loadbalancer"},"name":"webapp1-loadbalancer-svc"...
Selector: app=webapp1-loadbalancer
Type: LoadBalancer
IP: 10.105.60.108
LoadBalancer Ingress: 172.17.0.31
Port: <unset> 80/TCP
TargetPort: 80/TCP
NodePort: <unset> 30626/TCP
Endpoints: 10.32.0.14:80,10.32.0.15:80
Session Affinity: None
External Traffic Policy: Cluster
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal CreatingLoadBalancer 95s service-controller Creating load balancer
Normal CreatedLoadBalancer 95s service-controller Created load balancer
现在可以通过分配的 IP 地址访问该服务，在本例中的范围是 10.10.0.0/26 。
controlplane $ export LoadBalancerIP=$(kubectl get services/webapp1-loadbalancer-svc -o go-template='{{(index .status.loadBalancer.ingress 0).ip}}')
controlplane $ echo LoadBalancerIP=$LoadBalancerIP
LoadBalancerIP=172.17.0.31
controlplane $ curl $LoadBalancerIP
<h1>This request was processed by host: webapp1-externalip-deployment-6446b488f8-2zw2p</h1>
controlplane $ curl $LoadBalancerIP
<h1>This request was processed by host: webapp1-externalip-deployment-6446b488f8-dxdb5</h1>
